Product Description
Gas Fired Thermal Oil Heater siv cov roj hnyav, cov roj teeb lossis cov kua roj combustible li roj, thiab cov roj thermal ua cov khoom siv hluav taws xob. Lub twj tso kua mis ncig yog siv los yuam cov kua theem kev ncig, uas xa cov hluav taws xob hluav taws xob mus rau cov khoom siv cua sov, thiab tom qab ntawd rov qab mus rau qhov hluav taws xob ncaj qha tshwj xeeb rau kev ua kom sov.
Gas Fired Thermal Oil Heater Gas raug rho tawm haujlwm thermal roj rhaub yog dav siv hauv petrochemical, textile, luam ntawv thiab dyeing, yas, roj hmab, khoom noj khoom haus, ua ntoo, asphalt cua sov, thawv ntau lawm, zaub dehydration, xim ci, casting xuab zeb pwm kom qhuav, thiab lwm yam. Nws kuj tseem siv tau rau tsawg dua lossis sib npaug li 350oC ci, steaming, shaping, melting thiab ziab.
Gas Fired Thermal Oil Heater yog ib qho kev sib dhos yuam kev ntsug roj roj (gas) boiler. Cov cua sov saum npoo ntawm lub boiler lub cev ntawm cov koob no yog compact, thiab cov cua sov saum npoo yog tsim los ntawm cov txheej txheem sab hauv thiab sab nraud nruj nreem kaw. Lub puab kauj yog ib qho hluav taws xob cua sov saum npoo, thiab txheej txheej thiab txheej txheej ntawm lub coil sab hauv tsim ib qho convection cua sov nto. Gas Hluav Taws Xob Hluav Taws Xob Hluav Taws Xob Hluav Taws Xob Hluav Taws Xob los ntawm lub cev sab saud thiab qis qis chamber muaj pes tsawg leeg, qhov chaw sib xyaw ua ke. Tom qab lub combustion yog tag nrho cov kub nyob rau hauv lub combustion chamber, feem ntau ntawm cov tshav kub yog absorbed los ntawm lub radiant cua sov nto, thiab cov high-temperature flue gas nkag mus rau lub convection cua sov nto rau tshav kub exchanger, thiab heats cov cua yuav tsum tau los ntawm lub boiler combustion nyob rau hauv lub boiler combustion. cua preheater tom qab lub boiler yog tawm, thiab ces cov roj flue xa mus rau lub chimney los ntawm induced cua ntsawj ntshab ntxuam thiab tawm mus rau hauv cov huab cua.
Cov duab khoom
Khoom parameter
|
Qauv nab npawb |
YYQW-240 |
YYQW-350 |
YYQW-700 |
YYQW-1000 |
YYQW-1200 |
YYQW-1400 |
|
Thermal zog ntsuas (MW) |
0.24 |
0.35 |
0.7 |
1.0 |
1.25 |
1.4 |
|
Thermal efficiency% |
90 |
90 |
90 |
90 |
90 |
90 |
|
Tsim siab (MPa) |
1.0 |
1.0 |
1.0 |
1.0 |
1.0 |
1.0 |
|
Ua haujlwm kub siab tshaj plaws (degree) |
350 |
350 |
350 |
350 |
350 |
350 |
|
Lub tshuab hluav taws xob muaj roj (m3) |
0.21 |
0.25 |
0.28 |
0.44 |
1.1 |
1.2 |
|
Cov roj (m3/h) |
40 |
40 |
80 |
80 |
110 |
130 |
Kev nthuav qhia nthuav dav
Txais cov txheej txheem siab tshaj plaws, qib siab ntawm automation, txuag hluav taws xob thiab kev tiv thaiv ib puag ncig, muaj zog, ruaj khov, txuag sij hawm thiab txuag hluav taws xob, kev ua haujlwm siab
Cov cuab yeej yog siab heev thiab txhim khu kev qha, cov txheej txheem optimization yog zoo meej, layout yog tsim nyog, lub installation yog ceev, lub lag luam yog yooj yim, cov kev pab cuam yog ceev thiab xav.
Nrog cov khoom lag luam zoo thiab kev xav zoo tom qab muag, cov neeg siv nyob ib puag ncig qhuas!
Txog Peb
Tau ntau xyoo, Hebei Zhengneng Boiler Equipment Co., Ltd. tau nquag tsim lub zog txuag thiab ib puag ncig tus phooj ywg boiler khoom raws li kev lag luam boiler, thiab tau txais ntau lub teb chaws patents, thiab tau txais kev qhuas los ntawm cov neeg siv.
Kev cob qhia ntau lawm
Cov khoom siv ntau lawm
Cov khoom xa tuaj
Cim npe nrov: Gas raug rho tawm haujlwm thermal roj rhaub, Tuam Tshoj roj hluav taws xob thermal roj rhaub manufacturers, lwm tus neeg, Hoobkas
